5V Multi-Protocol Card RFID Reader Writer Module LMRF3060 Development Board UART/TTL Interface

More document click to download LMRF3030Features The LMRF3030 contactless card reader module encapsulates the communication protocol of the contactless card and the commonly used non contact card operation process in a small embedded module The user does not need to understand the complicated contactless communication protocol and does not need to read the card specification With a very simple serial communication interface and instructions you can operate a contactless card to perform complex card flow operations Support multi protocol ISO14443 Type A ISO15693 etc to make it more widely used Specifications 1 Card Reading Distance 50 100mm2 Interface serial port TTL level 232 level 3 Data Transmitting Spped Rate serial port 9600bps 19200bps 38400 57600 1152004 Supporting Card Type conform to ISO IEC14443TypeA TypeB ISO ICE15693 non touch card CPU card M1 bus card bankcard ID card purchasing card ETC 5 Operating Voltage 5V6 Module Size 40 60mm7 Antenna Size 55 80mm Package Included 1 x RFID Reader Writer Module
