5Pcs Waveshare® FT232 Module USB to Serial USB to TTL FT232RL Communication Module Mini Port Flashing Board

Features Use original FT232RLSupport Linux Android WinCE Windows 7 8 8 1 10 Support 3 power supply modes 5V external power supply 3 3V external power supply external power supply requires 3 3V 5V With 3 LEDs TXD LED RXD LED POWER LEDTXD RXD RTS CTS lead out with curved pinOther functions PIN reserved pad distribution pin row seat can be plugged into or plugged into the user system PIN spacing supports insertion into the universal board Instructions for use Take access to MCU as an example VCCIO output 3 3V or 5V module is powered by USB jumper cap must be jumped to 3 3V or 5V GND Connect to GNDTXD Connect to MCU RX Signal flow direction MCU RXFT232PC TX RXD Connect to MCU TX Signal flow direction MCU TXFT232PC RX RTS Connect to MCU CTS Signal flow direction MCU CTSFT232PC RTS CTS Connect to MCU RTS Signal flow direction MCU RTSFT232PC CTS Note This module is USB to TTL level do not directly connect to RS232 level otherwise the module will be burned Package includes 5 x FT232 USB UART Board Mini Port 10 x 5PIN header 5PIN header5 x Dupont cable Bulk head 6PIN to custom
