5Pcs NE555 + CD4017 LED Flash DIY Kit 3-5V Light LED Module

5Pcs NE555 + CD4017 LED Flash DIY Kit 3-5V Light LED Module
Eachine1
sku: 1020006
type: Electronic Components & DIY Kits
$5.62
Shipping from: China
   Description
5Pcs NE555 CD4017 LED Flash DIY Kit 3 5V Light LED ModuleFeature Power supply voltage 3 5VPCB Size 88 x 25mmThis kit is not included instruction Principle This kit is made up main circuit and decimal counter circuit from the core of the self excited NE555 multivibrator power through R2 R3 R4 charge the capacitor C1 C1 started when charging NE555 2 feet still in low so the output pin 3 goes high when power through R2 R3 R4 to charge C1 to 2 3 of the supply voltage the output pin 3 level from high to low NE555 conducting internal discharge capacitor C1 through R4 R3 NE555 7 feet discharge until the voltage across C1 is less than 1 3 of the supply voltage NE555 and 3 feet level from low to high C1 and charge again this cycle oscillations formed Charging time 0 695 R2 R3 R4 C1 discharge time 0 695 R4 R3 C1 R4 can be adjusted to control the output frequency of the oscillator the oscillation clock signal is applied continuously NE555 CD4017 14 feet the output terminal 10 is connected with the CD4017 10 LED when the output terminal 10 turns CD4017 generated clock signal is applied at a high level the D1 D10 are sequentially lit to form a water light effect You can adjust the flow rate adjustment R4 LED lights Note This is a DIY kit you need to assembly it This kit is not included the instruction Package included 5 x NE555 CD4017 LED Flash DIY Kit
