5Pcs CJMCU-3386 MC33186DH1 Automotive Computer Board Idle Speed Throttle Drive Board A H Bridge

Description The 33886 is a monolithic H Bridge ideal for fractional horsepowerDC motor and bi directional thrust solenoid control The IC incorporatesinternal control logic charge pump gate drive and low RDS ON MOSFEToutput circuitry The 33886 is able to control continuous inductive DC loadcurrents up to 5 0 A Output loads can be pulse width modulated PWM ed at frequencies up to 10 kHz A Fault Status output reports undervoltage short circuit andovertemperature conditions Two independent inputs control the two half bridgetotem pole outputs Two disable inputs force the H Bridge outputs totri state exhibit high impedance The 33886 is parametrically specified over a temperature range of 40CTA125C 5 0 VV 28 V The IC can also be operated up to 40 Vwith derating of the specifications The IC is available in a surface mountpower package with exposed pad for heatsinking Package included 5 x CJMCU 3386 MC33186DH1 Automotive Computer Board Idle Speed Throttle Drive Board
