5Pcs 16A PCB Protection Circuit Board Module Overcharge for 3.7V 1S 25/30 650-1200mAh LiPo Battery

5Pcs 16A PCB Protection Circuit Board Module Overcharge for 3 7V 1S 25 30 650 1200mAh LiPo BatteryDescription Item Name LiPo Battery Protection BoardRated Voltage 3 7VDischarge Current 16AOvercharge Detection Voltage 4 275 0 025VOvercharge Detection Delay Time 200msOvercharge Recovery Voltage 4 075 0 025VShort Circuit Protection Time 50usShort Circuit Protection Condition External circuit short circuitWorking Resistance 50mWorking Temperature 40C 55CStorage Temperature 20C 45CSize 22x5mmNet Weight 0 3gQuantity 5PcsUsage for 3 7V 1S 25 30 650 1200mAh LiPo BatteryFeatures Power MOSFET with high withstand voltage and low on resistance with over charge protection and short circuit protection The short circuit protection performance is stable and reliable Long term load short circuit will not affect the protection board and the battery core The single protection board has no over discharge protection Safe and stable Note 1 When testing and installing the product it is necessary to take strict anti static measures to avoid damage to the product due to electrostatic shock 2 In order to protect the protection board from accidental short circuit leakage and damage caused by interference please take the side of the PCB board with the battery wire and try to avoid passing the front and back of the PCB board 3 When welding the output wire it is necessary to select the power cable with the appropriate diameter to prevent the heat and line pressure d
