5MP 720P/1080P Mini Camera Module For Raspberry Pi Zero

Overview:It' s a customized mini camera for Raspberry Pi Zero V1.3With the small size, it can be integrated with RPi Zero into any application that has high command of demension.Feature:- Interface: CSI- 5 Megapixel OV5647 sensor- Max. Resolution: 2592 x 1944- Support 1080p30, 720p60, and 640x480p60/ 90 video- CCD Dimension: 1/4 inch- Diagonal: 72.4 degree- Sensor best solution: 720p,1080p- Dimension: 60mm x 11.5mm x 5mm Hardware connection:- Plumb to connect the FFC with the connector(the one right beside the HDMI interface). The contact face to the HDMI interface when connection.- Remove the protective film before using the lens.- Beware of ESD damage and static electricity when use the bare board.Software:- RPi raspi-config and firmware have been updated to the camera. Execute apt-get update and apt-get upgrade- Select camera in raspi-config, start up camera driver in RPI, and then boost- Perform the command-line procedure raspivid and raspistill to operate the camera, capture video clips or images- The captured video clips need to play with mplayerPackage included:1 x Camera Module
