5 OSD Game RR52C.04A Support Digital Signal DVB-S2 DVB-C DVB-T2/T ATV Universal LCD Driver Board Dual USB Play Media 40P

Manual http myosuploads3 banggood com products 20181221 20181221025051SKUA79627 pdfNote Support Digital Signal T2 S2 Description Model RR52C 04ASupport TV Signal DVB C T T2 S2 ATVSupport Language English Chinese French Espanol Deutsch Nederlands Portugues German Thai Vietnam Arabe Audio output power 2x8WConsumption operating mode 6W simple 0 3WVideo input TV DVB T T2 S2 DVB C ANALOG TV ATV HDMI VGA AV INInput Interface PC HDMI TV USB multimedia playingVoltage DC 12V 4AScreen interface LVDS 1CH 6 bitScreen voltage 3 3V 5V 12VResolution Support high screen 1920 1080 15 42 inch LVDS screenAdditional inputs outputs audio mini jack 3 5mm USB5 Built in OSD Games USB slot can be used for updating software and playing multi media such as Movie MP3 and JPEG text How to know if your panel suitable for this board Step 1 Find your LCD models resolution you can check the resolution from this link http www panelook com index php Step 2 Find and write in the corresponding firmware You can download the firmware from here http myosuploads3 banggood com products 20181221 20181221022350DANGKOURR52C04A rar Step of USB upgrade 1 Put the firmware of RR52C bin in formatted USB flash disk then insert the USB disk and the 7KEY Button to the board2 After turn on the power the light of the 7key button will be Red and flashing after about 1 minute the light stop flashing and be blue it means upgrade has finished Note that
