5-32A 110-130V 60Hz LCD Backlight Single Phase Energy KWh Meter DIN Rail Mounting

Features: 1.Adopt microelectronics and digital processing technology to measure electric energy accurate and reliable. 2.Internal integrated circuit is manufactured with precision SMT technology with good electromagnetic interference resistance and stable performance. 3.This energy meter can measure positive active energy in electric energy measurement which is clearly displayed by LCD backlight screen. 4.It circularly displays voltage current power and energy KWh. 5.Small size light weight 35mm DIN rail mounting. 6.It has low power consumption high precision high overload electricity anti-stealing. Specification: Model: DDS528L Rated voltage: 110-130VAC Rated current: 5-32A Load capacity: 0.05Ib - Imax (direct access type) or 0.02Ib - Imax (access via transformer) Data display: LCD display Power indication: Green light Electric energy pulse indication: Red light (When there is a sampling signal it lights for about 80ms) Mounting method: 35mm DIN rail Working environment: -25℃~55℃ ≤95%RH Size: 78.5*36.5mm / 3.09*1.44in Package weight: Approx. 134g/4.7oz Package list: 1 * Energy Meter 1 * Buckle 4 * Seal Cap Note: 1.Due to the difference between monitors and light effects the pictures may not reflect the actual color of the item. 2.Please allow slight error due to manual measurement. Thanks for your understanding.
