4~20mA PLC Signal Generator Current Transducer Test Two Wire Output

Features: No-source two-wire 4-20mA current loop wiring compatible with 2 3 4 wire system 9 programmable output (can simulate the actual environment of dynamic testing each section can be set up t running time /A current /b current). Digital rotary encoder adjustment (the use of potentiometer easily affected by temperature and humidity the resistance value will change). Can be connected to the positive and negative (two-wire system no matter how wiring can work will not burn meter). High precision good linearity (Output accuracy：±0.5％；Display accuracy：0.01) Coarse and fine adjustment modes can be set for quick and accurate adjustment Output range can be set: 4-20mA (control device) / 3-21mA (debug signal) Display mode: Actual current/100.0%/50.0Hz LCD (with backlight). Linear output calibratable Can be set to automatically store output values: automatic / manual 2-9 quick adjustment output points can be set Imported chips ultra-low power consumption no heat more stable output. The shell is beautiful and easy to install. System operation： Parameter Settings:（Rotate grid clockwise is + Rotate grid counter-clockwise is - Press the knob. is Confirm ） 1. Press and hold the knob for 2 seconds to enter the parameter setting Display parameter number F001 Then press Confirm to Set the value of parameter F001 =0 is coarse tuning; =1 Fine tuning; Then press Confirm to save its value. 2. When the parameter number FXXX is displayed + - Rotation modification parameter number; Enter the password first + - - + To enter the F002 parameter; Enter the password first + - + - To enter the F100 parameter; Enter the password first - + - + To enter the F200 parameter. Specification: Power supply voltage: 15V-30V Output range: 4-20mA/3-21mA Display mode: Real Current / 0-100.0%/ 0-50.0Hz Sampling resistance: Less than 500 ohms Output accuracy: ±0.5％ Display accuracy: 0.01 Shell material: ABS Dimensions: 79.5x42.2x24mm/3.13x1.66x0.94inch Color: Black Quantity: 1 Pc Note: 1.Please allow 0-1cm error due to manual measurement. pls make sure you do not mind before you bid. 2.Due to the difference between different monitors the picture may not reflect the actual color of the item. Thank you! Package includes: 1 x Current Loop Signal Generator 1 x User Manual (English)
