4V220-08C 1 PCS 1/4" 2 Position 5 Port Air Solenoid Valve 4V220-08C Pneumatic Control Valve, AC 110V CE

4V220-08C 1 PCS 1/4" 2 Position 5 Port Air Solenoid Valve 4V220-08C Pneumatic Control Valve, AC 110V CE
sku: 2051586677
$69.99
Shipping from: China
   Technical Details
Dimension: 171mm x 66.7mm x 22mm
Effective area: 16mm2(CV=0.89)
is customized: Yes
Material: Alloy
Max. proof pressure: 1.5Mpa
Media: Air (filtered by 40μm filter element)
Model Number: 4V220-08C
Operating Pressure: 0.15~0.8MPa
Operating Voltage: AC 110V
Port Size: Air inlet=Air outlet=G1/4" Exhaust=G1/8"
Power: Pneumatic
Pressure: Low Pressure
Protection: IP65
Standard or Nonstandard: Standard
Structure: Pilot
Temperature of Media: Normal Temperature
Valve Type: 5 port 2 position
Weight: 320g
