4PCS NHYTech SG90 9g 4.8-6V Mini Analog Servo Smart Horn For RC Fixed Wing Airplane Model Robot Parts Motor DIY Models

Specification Model SG90Size 22 9 12 2 30mmWeight 9gApply Environmental Condition Storage temperrature range 20 60℃Operating temperrature range 10 50℃Operating voltage range 4 8 6vEletrical specification Operating speed at no load 0 12±0 01 sec 60 4 8v 0 1±0 01 sec 60 6v Running current at no load 200±20mA 4 8v 220±20mA 6v Stall torque at locked 1 3±0 01kg cm 4 8v 1 5±0 1kg cm 6v Stall current at locked 600mA±50mA 4 8v 700mA±50mA 4 8v Control specification Control system Change the pulse widthAmplifier type Analog controllerOperating travel 90°±5° 1000 2000u sec Left and right travelling angle deviation ≤5°Centering deviation ≤1°Neu position 1500 u secRotating direction Counter clockwise 1500 1000u sec Pulse width range 800 2200u secMaximum travel about 135° 800 2200u sec Package included 4x SG90 9g 4 8 6V Micro Analog Servo for Fixed Wing Aircraft RC Model
