48V BMS Balance For 13S 30A Li-ion Lithium Battery Protection Board With Cable

Specification: Name: Protection board Model: 578849 Charging voltage: DC 54.6V CC/CV Balance voltage for single cell: +/-25mV Current consumption: 20A Maximal continuous charging current: 5A Maximal continuous Discharging current: 30A Over charge detection voltage: 4.250.025V Over charge detection delay time: 1000ms+/-100ms Over charge release voltage: 4.050.025V Over discharge detection voltage: 2.750.025V Over discharge detection delay time: 100mS+/-10ms Over discharge release voltage: 3.00.025V Over current detection current: 605A Protection circuitry: 20m Release condition: Cut load Detection condition: Exterior short circuit Operating Temperature Range: -40~+70 Short circuit protection function: There is disconnect the load can be self recovery. Size: 70x45x15mm Main function: Over charge protection, over discharge protection function, short circuit protection function, over current protection function, band balance. Package Included: 1 X Protection Board 1 X Cabel Wire
