433mhz LoRa1262 SX1262 LoRa RF Module 22dBm 160mW 1.5ppm TCXO SPI Spread Spectrum Wireless Transceiver Module
Feature: The LoRa1262 wireless module uses Semtech's SX1262 device, which uses a high-precision TCXO crystal oscillator, ultra-low receive current and sleep current, and sensitivity of -148dBm. Built-in 64KHz crystal oscillator can wake up the microcontroller periodically under low power consumption. The module antenna switch is integrated and controlled by the chip, which saves the resources of the external MCU. The compact size and 22dBm (160mW) output power have great advantages in IoT and battery-powered applications. Parameter: Frequency Range: 433MHz Sensitivity: up to -148dBm @Lora Maximum output power: 22dBm (160mw) Data transfer rate: 0.018-62.5 Kbps Packet engine: up to 256 bytes with FIFO and CRC With TCXO, accuracy 1.5pp Performance parameters: @Vcc=3.3v ANT connected to 50 ohm load Receive current:
