433MHz AC220V 1 Channel Wireless Remote Control Switch Module Learning Code 1CH Relay Module with Waterproof 2 Key Transmitter

Features: The learning 220V single-way two-terminal connection resistance-capacitance remote control switch adopts 10A relay and can load 1500 watts of electrical appliances. It can learn multiple remote controllers, and all keys of each remote controller can be learned. It can control multiple switches by one remote controller or one switch by multiple remote controllers. It is easy to operate, flexible and arbitrary combination. Mainly used in lamps, electric doors, windows, lifting equipment, gates, lifts, industrial control and security industries and other fields. Specification: Model: CXAC-1A+AK-SOS Remote control distance: 10-30 meters Operating Voltage: AC180-240V Working frequency: 433 MHz Load: less than 1500W Working mode: self-locking, jog and interlocking (through pad switching) Circuit Board Size: 54.4 x 31.7 x 17mm Shell size: 74 x 36 x 23 mm Learing method: Turn on the 220V power supply, press and hold the learning button for three seconds, then press any button on the remote control. The indicator flashes, indicating that the learning is successful. Note: This controller can learn the fixed code (PT2262, SC2260 chip, etc.) / learning code (EV1527, HS2240, etc.) 20 different encoding, any button remote control, beyond it will remove the earliest learned remote control. Clear method: Press and hold the learning button for about 8 seconds. The indicator will turn off and return to light. Work mode switching: Use the pin on the remote control switch to use the short circuit connection 1, 2, 3 to switch the working mode. 1. Jog - 1, 2, 3 short circuit vacant, no connection 2. Interlocking - shorting 1, 2 3. Self-locking - shorting 2, 3 The meaning of self-locking/interlocking/jogging: Interlock: Press the corresponding button of the remote control, the corresponding relay is turned on, and then press another remote control button; the relay is disconnected. Non-lock, jog: Press the remote control button, the corresponding relay is turned on, release the remote control button; the corresponding relay is disconnected. Self-locking: Press the remote control button once, the relay is turned on, press the remote control button again, the relay is disconnected. 2-button wireless remote control technical parameters: Working voltage: DC06V (2 CR2016 3V batteries) Working current: 15mA Quiescent current: 0mA Working frequency: 433MHz Chip type: fixed code (2260) learning code (EV1527) Oscillation resistance: commonly used 4.7 Launch distance: 10-30M (in an open environment) Modulation method: ASK amplitude modulation Size: 56.36*31.58*11.03mm Package included: 1 x 433 MHz 220V 1 Channel Wireless Remote Control Switch Module
