433MHz 1W LORA6102AES High Power Long Distance Serial to Wireless Module Transparent Transmission Antenna

Introduction: The LoRa6102AES is an industrial-grade wireless serial transmission module with an aluminum alloy casing. It is based on the high-power wireless data transmission module developed by Semtech's SX1276/1278 chip. The device uses LoRaTM spread-spectrum modulation frequency hopping technology for efficient receiving sensitivity and Superior anti-interference performance, plus external integrated PA device to make its communication distance and receiving sensitivity far exceed the current FSK and GFSK modulation. The block performs AES128 encryption processing on wireless data, making data transmission more secure and superior. Anti-interference. Feature: The airborne transmission distance can up to 8000 meters @low rate Operating frequency band: 433/470 (1W) MHz, 868/915 (500mW) MHz Up to 40 communication channels Diversified serial port parameters LORA modulation mode TTL/232/485 level interface Sensitivity up to -139 dBm Output power: 1W (+30dBm) 500mW (+27dBm) Operating voltage range: 3.3 ~ 6.5 V Operating temperature range: -40 ~ +85 C Application: Wireless remote telemetry Remote meter reading security system Industrial data collection Home automation telemetry Wireless data communication Access control system Robot control Performance parameters: Note: The module is internally regulated by 3.3V LDO. The CS pin and SET pin control are 3.3V levels. The serial TXD and RXD pin outputs and inputs support 3.3V levels. Parameter Minimum Typical Largest Unit Condition Operating conditions Operating voltage range 3.3 6.5 5 V Working temperature range -40 25 85 Current consumption Receiving current
