3pcs JDY-10M 4.0 bluetooth Module Master-Slave Support MESH Networking App Transmission
Product introduction: The JDY-10 transmission module is a bluetooth 4 protocol standard, the working band is 2. 4GHZ range, the modulation mode is GFSK, the maximum transmission power is 8dB, the maximum transmission distance is 50 meters. It has the characteristics of low power consumption, small size, strong signal, stable data transmission and so on. Product features: 1: supports the transmission of Android and IOS mobile phones. 2: Supports one-to-many, many-to-one, many-to-many data transmission and control. 3: Supporting network LED lamp (26 scenario mode, panel mode) brightness, white light, adjustable speed. 4: Supports networking GPIO control (one-to-many, many-to-one, many-to-many). 5: can be certified by FCC/CR and other standard. 6: Supporting networked remote control (ultra-low power consumption) two dry batteries can be used for at least one year. 7: support network 4 way PWM control. 8: The maximum number of 8: networks is 255. 9: supports broadcast and unicast MESH to send data. 10: supports BLE master-slave operation without master-slave switching. 11: at least 60% of the smart home application JDY-10M can be competent. Product application scope: 1: bluetooth networking LED lights (one to many, many to one, mobile phone or remote control, many to many control ). 2: bluetooth network motor pulling applications (one to many, many to one, machine or remote control, many to many control). 3: network panel switch, 86 switch (ultra-low power consumption). 4: network smart home application (control, relays, curtains) control. 5: networking sensor Application of network gateway of. 6: Application of network gateway of WIFI. 7: Application of Zigbeel network. 8: Application of mobile phone network control. Technical specifications: Type Specification parameter Working voltage 1.9 - 3.6V Working temperature -40 - 85 Maximum emission power +8dbm Antenna PCB board antenna Receiving sensitivity -92dbm SMT welding temperature Set / query - short address of networking: Instruction Response Parameter AT+MADDR OK Param (2 bytes) Default: one bit after MAC address (HEX) AT+MADDR +HADDR= Setting / checking the -APP connection password: Instruction Response Parameter AT+PSS +0K param: (2 bytes) Default:12345 AT+PSS +PSS= Set / check a APP cipher connection switch: Instruction Response Parameter AT + ISCEN OK Param: (1 bytes) 1: hit the APP password switch 0: APP connections do not require a password Default: 0 AT+ISCEN +ISCEN= Set / check - the short address of the key switch: Instruction Response Parameter AT+KVALUE +0K Param: (4 bytes) 01FF: indicates that K1 is configured as a broadcast mode. When K1 is pressed, all devices will receive K1 key values. 0108: means that K1 is set to unicast. When K1 is pressed, only the device's short address is 08 of the device receiving the K1 key. 02FF: means that K2 is set to broadcast mode. When K2 is pressed, all devices will receive K2 key value. 0208: means that K2 is set to unicast. When K1 is pressed, only the device's short address is 08 of the device receiving the K2 key. 03FF: indicates that K3 is configured as a broadcast mode. When K3 is pressed, all devices will receive K3 key values. 0308: means that K3 is set to unicast. When K3 is pressed, only the device's short address is 08 of the device receiving the K3 key. 04FF: means that K4 is set to broadcast mode. When K4 is pressed, all devices will receive K4 key value. 0408: means that K4 is set to unicast. When K4 is pressed, only the device's short address is 08 of the device receiving the K4 key. 05FF: means that K5 is set to broadcast mode. When K5 is pressed, all devices will receive K5 key value. 0508: means that K5 is set to unicast. When K5 is pressed, only the device's short address is 08 of the device receiving the K5 key. AT+KVALUE +KVALUE= Param2: (2 bytes) 01: means to read the address of the K1 02: means to read the address of the K2 03: reads the tore of K3 04: means to read the address of the K4 05: farmer reads K5's address The number of serial ports MKSH is transmitted :(one to many, many to one, many to many) instructions Target short circuit address Data AAFC 2byte Param Serial MKSH data receiving: instructions Target short circuit address Data long Data AA lByte lByte lOByte BB lByte lByte lOByte Serial
