3pcs EU Plug CCTV Security 48V 0.5A 24W POE Wall Plug POE Injector Ethernet Adapter IP Camera Phone PoE Power Supply

Main Specifications 1 Power InputRated Voltage range AC100 240V Frequency range 47 63Hz Efficiency 80 min AC current 0 7A max 2 Power OutputRated voltage DC48V Rated current 0 5A Current range 0 0 5A Ripple 480mVp p Rated power 24W Voltage tolerance 3 0 poe pin 45 78 Data Pin 12363 Power ProtectionProtection Short circuit Over load protection Over power protection4 EnvironmentWorking temp 0 40C Working humidity 20 90 RH non condensing Storage temphumidity 20 85C 10 95 RH Vibration EN 61131 2 Working distance Max 100m5 SafetyEMCStandards design refer to EN60950 Withstand voltage I P O P 3KVAC 5mA 60S Isolation resistance I P O P 100M ohms 500VDC EMC EN55022 Class BApplication For wireless Access Points Routers IP phones IP cameras modems switches embedded computers or other network devices Important tips This poe injector is compatible with IEEE802 3af poe device PD or non poe device through IEEE802 3af poe splitter the poe PD poe splitter must support PoE pin 4 5 7 8 in 10 100Mbps Base T lan environmentHow to connect At the starting point The poe injector connected to 1 Power socket2 Network switch router computer host At the ending point 1 To powered PoE device PD PD must support poe pin 45 78 2 To powered NON poe device which requires a standard IEEE802 3af poe splitter poe splitter non poe device a poe device the poe splitter must support poe pin 45 78 Package i
