3pcs DC12V 10A 1CH 433MHz Wireless Relay RF Remote Control Switch Receiver Board

Specification 1 Input Voltage DC10 14V2 Standby Current 5MA3 RF Frequency 433MHZ4 RF Working mode Super heterodyne receiver5 Receiver Sensitivity 90dBm6 Remote Control Distance 100 meter In open environment 7 Decoding Way MCU Software decoding8 Can store the number of remote control 509 Support remote control type Fixed code learning code10 Channel 1CH11 Multiple working modes Jog Non Latched inter lock Latched self lock Self Latched Delay off 12 Wiring Method Fixed wiring terminal13 Working Voltage DC12V14 Output Current 10A15 Rated load 10A 250VAC 10A 125VAC10A 30VDC 10A 28VDC16 Output Normally open Common Normally closed17 Dimension 3 5cm 3cm 1 6cmWorking output way 1 Jog Press the learning button then release set the mode from the system automatically working mode to action mode wait for a while when the board LED off said it is into the learning state press the remote control the system received the signal The LED flashes 5 times and goes off again After 3S delay LED light marked learning success the system automatically withdraw from the learning state 2 Self locking Press the learning button then release press 2 times the system automatically set to self locking mode wait for a while LED off it is into the learning state press the remote control LED flash 5 times Off 3S after the delay LED light learning success 3 Interlock press the learning button then release press 3 times in succession the system is set to interlock mod
