3pcs 7V to 45V Microstepping ST820 Stepper Motor Driver + Heatsink for 3D Printer RAMPS

Description ST820 is a compact and easy to use evaluation board for the STSPIN820 the worlds smallest 45V microstepping motor driver Features Supply voltage from 7V to 45VOutput current up to 1 5A rms for each motor phaseMaximum current up to 2 5 A per phase Integrated low RDS ON power stages HS LS 1typ It helps customers to really exploit the benefits of working at high microstepping resolution The microstepping resolution can be easily set to one of eight available values through M1 M2 and M3 inputs full step 1 2 1 4 1 8 1 16 1 32 1 128 and 1 256 of step Can adjustable current control through a potentiometer to set the ref voltagesEmbedded PWM current control with selectable decay mode fast or slow The hardware is fully compatible to be used together with RAMPS or other similar FFF 3D printing platforms representing a very fast drop in replacement of similar solutions It provides a very compact solution to evaluate the performance of the STSPIN820 stepper motor driver with a minimum set of additional equipment and without the need for additional devices The STSPIN820 features a full set of protections Stepper motor driving with a microstepping resolution up to 1 256th of stepOvercurrent short circuit and overtemperature protection Package Included 3 x Microstepping ST820 Stepper Motor Driver Heatsink
