3mm Shaft DC 6.0V 30RPM Gear Motor Electric Gear Box Motor

Description: 3mm Shaft DC 6.0V 30RPM Gear Motor Electric Gear Box Motor Specification: Material: ABS+ Cu + Fe + steel DC voltage: DC 6.0V No-load speed: 30rpm Shaft diameter: 3mm Length: 10mm of type D 1. Standard Operating Conditions Item Specification Rated Voltage DC 6.0V Gear Ratio 1/298 Rotation CW Motor Position All position in horizontal Temperature 0 - 30 Degree Celsius Humidity 30% - 95% 2. Performance of Motor Item Specification No-load Speed 10500 +/- 10%rpm No-load Current 25mA (Max) Stall Current 200mA (Max) Stall Torque 8g.cm 3. Performance of Gear Motor Item Specification Outer Speed 30 +/- 10%rpm No-load Current 40mA (Max) Stall Current 200mA (Max) Stall Torque 2.0kg.cm Rated Torque 300g.cm Rated Current 65mA (Max) Rated Speed 26 +/- 10%rpm Noise 48dB 4. Dimension Item Specification The Outside Shafft Length 10mm Shaft End Play 0.05 - 0.30mm Screw Size M1.6 X 0.35 Diameter of Shaft 3mm Outline Mounting Dimension Refer to the Outline Drawing 5. Product Drawings 6. Curve Drawings Package Included: 1 x Gear Motor 1x Plastic Bracket More Details:
