3S 12V 25A Li-ion Lipo Battery 18650 Board Charger Protection Cell Charging Module Electronic BMS Packs PCM with Balance

3S 12V 25A Li-ion Lipo Battery 18650 Board Charger Protection Cell Charging Module Electronic BMS Packs PCM with Balance
thumb
thumb
thumb
thumb
thumb
thumb
sku: 32963846252
ACCORDING TO OUR RECORDS THIS PRODUCT IS NOT AVAILABLE NOW
$2.11
Shipping from: China
   Technical Details
Brand Name: ACEHE
Charging Voltage: 12.6V-13V
Color: Green
DIY Supplies: Electrical
equalizing current: 45 mA
Life: more than 30000 hours.
Max Peak Current: 35-40A
Max Working Current: 20-25A (pay attention to heat dissipation)
Model: HX-3S-FL25A-A
Model Number: Li-ion Battery Protection Board
Over charge voltage range: 4.25-4.35V + 0.05V
Over discharge voltage range: 2.3-3.0V + 0.05V
Quiescent Current: less than 30uA
Resistance: less than 100m ohm.
Short Circuit Protection: yes, self recovery delay
Storage Condition: -40-- +80C
Type: Household Battery Tester
Working Temperature: -40---+50C
