3S 11.1V 12V Lipo Battery Protection Board With Balance Function

3S 11.1V 12V Lipo Battery Protection Board With Balance Function Description: Item Name: Lipo battery protection board Item NO.: HX-3S-FL25A-A Charge Voltage: 12.6V - 13V Charge Current: 25A (Max) Continued Overcharge Current: 25A Instantaneous Overcharge Current: 75A Overcharge Voltage Range: 4.25-4.35V 0.05V Overdischarge Voltage Range: 2.3-3.0V 0.05V Max Working Current: 20-25A Max Instantaneous Current: 35-40A Balanced Current: 45mA Quiescent Current: 3000h Weight: About 10g Dimension: 56*45*4.0mm Features: Upgraded verison,the working current is up to 25A. With balance function,can balance the voltage when charging. With overcurrent,overcharge and overdischarge protection function,well protect your battery. Note: Discharge product that with more than 3A current,please make sure that the discharging rate is larger than 3C. Please follow this method strictly to wiring,0V (B-) 3.7V(B1) 7.4V(B2) 11.1V(B+). After wiring,need to charge, then will have output. When connecting three groups of batteries, please ensure that the voltage of each group of batteries is the same, if not, please fill each battery separately and then use in series. In discharge test, the battery voltage drop the fastest, means that group is poor battery. Do not mix a good battery and a poor battery. 3 groups battery capacity / internal resistance,the closer the better. Package Included: 1x 3S 11.1V 12V Lipo Battery Protection Board (only a board)
