3Pcs Microwave Doppler X-Band Radar Sensor Wireless Module Motion Speed

Description: This HB100 Miniature Microwave Motion Sensor is a X-Band Bi-Static Doppler transceiver module. Its built-in Dielectric Resonator Oscillator (DRO) and a pair of Microstrip patch antenna array, make it ideal for OEM usage in motion detection equipment. This module is ideally suitable for false alarms reduction in intruder detectors when work together with Passive Infrared (PIR) sensor. It can also be used for auto-door opening and vehicle speed measurement. Features: Great replacement for failing or faulty Doppler radar microwave motion sensor module Highly resistant to radio-frequency interference Detection range: Over 20 meters Output power: 5mW Dimension(L x W x T): Approx. 1.75 x 1.45 x 0.3 inch / 4.4 x 3.7 x 0.8cm Non-contact detection Independent of temperature, humidity, noise, airflow, dust, light, etc. suitable for harsh environments Strong resistance to RF interference Low cost & Low Power Consumption. RF the Microwave Sensor.and use Doppler principle. Specifications: Transmitter: Frequency : 10.525GHz Frequency Setting Accuracy : 3MHz Power Output (Min.) : 13dBm EIRP Operating Voltage : +5V +/- 0.25V Operating Current (CW): 60mA max, 37mA typical Harmonic Emissions: -10dBm Receiver: Sensitivity (10dB S/N ratio) in 3Hz to 80Hz band width : -86dBm Noise in 3Hz to 80Hz band width : 10V Antenna Gain : 8dBi E Plane 3dB Beamwidth : 36'. H Plane 3dB Beamwidth: 72' Application: Security alarms and sensors Automatic door and gate systems ATM machines Car, van and lorry reversal warning systems Light sensors Traffic observation and control applications Package included: 3 x sensor
