3Pcs Electronic Dice DIY Kit 5mm Red LED Interesting Parts NE555 CD4017 Electronic Production Suite

Description Electronic dice kit is based on the NE555 oscillator circuit and fun circuit CD4017 counter display kit Can simulate the dice make fun of the game Parameters Supply voltage 4 5 5VDimensions 74 x 35mmNote This is a DIY kit you need to assemble it Quantity 3 setFunction When a power up 7 LED will randomly display a number of points players press the switch S1 7 all lit LED only after about 7 seconds LED light starts blinking until finally showed stable points Throughout the end of the first crap process Circuit Circuit mainly by the pulse generator and a decade counter circuit Pulse generator and external elements by NE555 multivibrator when you press the button S1 when Q1 turns on the output pulse NE555 3 feet then five turns the output CD4017 output high resistors and transistors by different combination can drive seven LED light to indicate the number of points 1 6 points Circuit diagram
