3Pcs AC-DC 220V to 12V 5V Fully Isolated Switching Power Supply Board

Feature: The power supply is fully isolated industrial grade built-in power module with temperature protection, overcurrent protection and short circuit full protection, AC85 ~ 265V wide voltage input, high and low voltage isolation, DC12V1A 5V1A dual isolated output voltage, 431 regulated, output with EMI filter circuit, with light, with mounting holes, cost-effective. Specification: Working temperature: -20 to 60 Relative humidity: 40% RH - 90% RH Input voltage range: 85V - 265V (typical: 110/220) (under full load conditions) Input Current: 0.027 (AC110V) 0.0136 (AC220V) (under full load conditions) Input surge current: 20A (under full load conditions) Size: 7.5 x 4.0 x 4.0 (cm) Output regulation characteristic: Output voltage Minimum current Maximum current Peak current Output voltage range Ripple +12V 0A 1A 1.2A 11.80~12.5V 150mV +5V 0A 1A 1.2A 4.90~5.1V 80mV Other output characteristics: Item Unit Min Typical values Max Test Conditions Output Power W 0 17 18.5 DC output power Output efficiency % 84 Rated load Boot shutdown overshoot % 10 The output rise time mS 100 Protection: Item Unit Yes/No Min Typical values Max Recovery characteristics Output voltage V 13 13.5 Lock, restart after recovery 5 5.4 Lock, restart after recovery Output Power Protection Yes 17 19 Lock, restart after recovery Short circuit protection Yes Lock, restart after recovery Temperature Protection Yes 90C 105C Lock, restart after recovery Overcurrent protection Yes Lock, restart after recovery Package included: 3 x Fully Isolated Switching Power Supply
