3Pcs 15A BTMOS-V2.0 MOS Tube High Power Heated Bed Expansion Power Module for 3D Printer

Introduction BTMOS V2 0 is a new module designed to solve the problem that the old hot bed power expansion module can not be equipped with high power hot bed and serious heat BTMOS V2 0 hot bed power expansion module can be connected with high power hot bed withstand more power convenient for machine use reduce the risk caused by heat Specifications Under the premise of normal heat dissipation Maximum current 15A Do not exceed 15A during use Size about50 60mm Wiring instructions 1 DCIN is connected to the positive pole of the power supply is connected to the negative pole of the power supply supports 12V or 24V power supply it is recommended to use 24V power supply 2 HOTBED the hot bed line no positive or negative points 3 J2 Connect to the hot bed control port on the main control board no positive or negative points Precautions 1 When connecting the power cord Pay attention to the positive and negative polarity of the power supply Do not reverse the connection to avoid burning the module and causing unnecessary loss 2 Module placement problem When using the module do not place it in a place where the wires are dense which will help reduce the heating load of the module and increase the safety 3 When the module is working Do not touch the conductor to the bottom to prevent the short circuit from burning Package Included 3 x Heated Bed Expansion Power Module with wire
