360 Degree Rotary Encoder Module Encoding Module

Functional characteristics and technical parameters 1 Nominal voltage DC 5V2 Wire A B 0 5mA Max 5mA Min 0 5mA 3 Common wire 1mA Max 10mA Min 0 5mA 4 Temperature range 30℃ to 80℃5 Output signal A B phase position output square wave when clockwise rotation A phase positionpull ahead B phase position90 when anti clockwise B phase position pullahead A phase position90 Size 27mm 24mm Pin introduction 1 2P port VCC DC 5V GND 2 3P signal output port A phase position B phase position C GND Package included 1 x 360 Degree Rotary Encoder Module For
