360° Automatic Infrared PIR Motion Sensor Switch for LED Ceiling Light AC220-240V

Specification: Voltage:AC220-240V 50Hz Wattage:1200W(incandescent lamp),300W(energy-saving lamp) Delay time:7 sec2 sec(min) 7 min2 min(max) Lumen:10-2000Lux(adjustable) Detection angle:360 Detection distance:6M(24) Feature: 1.Can identify day and night: The consumer can adjust work ambient light. It can work in the daytime and at night when it is adjusted on the "sun" position (max). It can work in the ambient light less than 3LUX when it is adjusted on the "moon" position (min). As for the adjustment pattern, please refer to the testing pattern. 2.Time-Delay is added continually: When it receives the second induction signals after the first induction, it will compute time once more on the basic of the first time-delay rest. 3.Time-Delay is adjustable. It can be set according to the consumer's desire. The minimum time is 7sec2sec. The maximum is 7min2min. Test: 1.Turn the TIME knob to minimum (-) position with anti-clockwise. Turn the LUX knob to SUN position with anti-clockwise. 2.Switch on the power; the controlled load and indication lamp both are not working. Preheat 30 sec later, the load and indication lamp should be turned on synchronization. In the absence of no inductor signals, the load should be stopped working within 5-30sec, the indicator lamp is turned off. 3.After the first sense is finished, and it will sense again after 5~10sec. The load should work. When there is no inductor signals in the indicator lamp, the load should be stopped working within 5-15sec. 4.Turn LUX knob clockwise on the minimum (MOON position). If it is adjusted in the less than 10LUX, the inductor load should not work after load stop working. If you cover the detection window with the opaque objects (towel etc) the load work .under no induction signal condition, the load should stop working within 5-15sec. Note: When testing in daylight, please turn LUX knob to (SUN) position, otherwise the sensor lamp could not work. Package included: 1*infrared motion sensor switch
