35mm Hinge Jig Vertical Boring Jig Drilling Guide Fixture Self Centering Dowelling Hole Puncher - package 2

Description: Multi-Function tool kit is suitable for hinge punching positioning vertical punching panel dowel punching side panle line drawing. 5/6/8/10mm drill bushings stable and with strong clamping force when drilling. 5 bushings easy to exchange for different drill needs. Quality metal material wear-resistant corrosion resistance longevity. 4 Functions in 1 tool: 1. 35mm Hinge punching supports 46mm 48mm 52mm hinge cup screw holes; 2. Vertical puncher; 3. Draw the center line on the side of the board; 4. Dowel puncher. Specification: Material: Metal Package 1: 1* Multifunctional Puncher 1* 2mm Drill Bit 1* 35mm Drill Bit 1* Copper Sleeve 12mm 4* Drill Sleeves 5/6/8/10mm 2* Positioning Pins 1* Allen Wrench Package 2: 1* Multifunctional Puncher 1* 2mm Drill Bit 1* 35mm Drill Bit 1* Copper Sleeve 12mm 4* Drill Sleeves 5/6/8/10mm 3* Dowel Drill Bits 6/8/10mm 1* Pencil 60* Wood Pins 6/8/10mm 1* Allen Wrench Size Chart: Diameter: 98mm Drill Bushings: 5mm / 6mm / 8mm / 10mm Hinge Holes Distance to Edge: 3mm/4mm/5mm/6mm Hinge Cup Screw Mounting Holes: 46mm/48mm/52mm Package Includes: 1 Set Dowelling Hole Puncher Kits 1 Piece Manual Note: Color might be slightly different due to the color calibration of each individual monitor. Please allow slightly measuring deviation due to manual measurement.
