350W Gear 13T Face Mount 24 V DC electric motor f bicycle bike Go-Kart ZY1016z3

BRAND NEW MY1016z3 type replacement motor for electric scooter mini bike quad Go-Kart or electric bicycle. 13T sprocket shipped loose 24V 350W GEAR REDUCTION MOTOR (BRUSH) Note: 13T sprocket shipped loose customer needs to install. caution - nut has reverse thread to loosen it turn clockwise while holding the sprocket. Specs: - 24V DC - Permanent Magnet DC Brush Motor - Reversible by changing polarity - 12 gauge leads - Reduction Ratio: 9.78:1 - Direct Drive (No Free Spooling) - Suitable for Forward and Reverse Operations - Face Mount Model - Chain drive (9 teeth sprocket + a loose 13T sprocket) #410 chain 1/2 (0.5in) pitch (12.7mm) (Bicycle chain) - Compatible with standard bicycle chain ZY1016Z3 350 Watt 24 Volt Specifications. Gear reduction 9.78:1 MotorShaftMotor Ref. PointTorque N.mTorque ft.lbfSpeed RPMTorque N.mTorque ft.lbfSpeed RPMPower Out WattPower Out HPVoltCurrent AmpsPower In WattEfficiency % No Load0.020.0139030.200.143999.210.0124.111.8945.5720.21 Max Efficiency0.630.4735346.164.56361261.610.3524.0913.56326.6880.08 Rated Load0.880.6533298.616.37340350.160.4724.0918.36442.3279.16 Max. Torque1.361.01300013.309.84307480.850.6424.0826.87647.0874.31 Dimensions: - Diameter: 4 - Roller Diameter 0.3 in - Roller Width 0.16 in Note: This motor is capable of rotation in either the clockwise or counterclockwise direction by reversing the motor s power wires. This motor will work with Razor Dirt Quad Scooter 24V or other electric scooters quads or go-karts using a 350 Watt motor. Specially good for DIY bicycle entisiasts as the drive is compatible with standard bicycle chains (1/2 pitch) Please check connector type and motor size and specs. before buying as replacement. Please ask us if you need to know any specific dimensions for this motor so you can be sure it will work for you. Most orders ship same day from our warehouse Warranty: 1 year from purchase date. We will only replace motors that do not work out of the box. We test all motors before shipping. We will not replace burnt out motors.
