3406E C-15 C-16 Injector Height Adjust Tool Engine Barring Socket Set for Cat

Function--Injector height tool-Accurately adjust the injector height of the engine; Engine barring socket--Turn over engine makes adjusting injectors and valve lash easier It was able to pin flywheel. Material-- Durable steel for engine barring socket. Aluminum alloy construction with anti wear property for injector height gauge tool. Package included 2 Tools — 9U-7227 Injector Height Tool 9S-9082 Engine Barring Socket. This is a non-OEM product accessory only! Application: Works for Caterpillar 3406E C-15 C-16Use Instruction: 1. When you finish the valve adjustments to the injector height you can use the tool to accurately adjust the injector height to 78. 0 ± 0. 2 mm (3. 07 ± 0. 01 inch). Tip: The dimension is measured from the top of the unit injector to the machined ledge of the fuel injector body. 2. Tighten lock nut to a torque of 100 ± 10 N·m (74 ± 7 lb ft). Application: Works for Caterpillar(CAT) engines 3200/3406 series C13/C15/C16/3208/3400/3406e/3508/3512/3500.
