315/433MHz Electric Copy Remote Control 4 Keys Garage Gate Wireless Switch, 501 Original

315/433MHz 4 Buttons Electric Copy Remote Control Motorcycle Garage Gate Door Opener Wireless Switch Duplicator ControllerSpecification:Working Voltage: DC 6VWorking Current: 14mAQuiescent Current: 0mAWorking Frequency: 315/433MHz (Optional)Transmitting Power: 10mWLaunch Distance: 100m/328.01ft (Open Environment)Product Size: 60 X 30 X 10mm/2.36 X 1.18 X 0.39\"Application: Copy and Restore of wireless remote controls such as barriers, garage doors, cars/motorcycles, etc.Copy Remote Control Applicable Scope: Ordinary Fixed Code (Chip Type 2260, 2262, 2264), Learning Code (1527, 2240) Remote Control.Instruction:1. Code Pairing (Learning)Place the original remote control and the copy remote control as close as possible, first press a button of the original remote control, and then press a button of Copy Controller immediately after the indicator light turns on for about 3 seconds, the LED will flash 3 times and then quickly flashing, it means that the address code of the original remote control button has been learned successfully. The other buttons are operated in the same way for learning.2. Clearing the Code:Press the unlock key and the lock key at the same time for 2 seconds, and the LED light starts to flash 3 times. At this time, keep pressing the lock key and release the unlock key. Press the unlock key 3-4 times within 5 seconds, and the indicator light flashes quickly. The code has been cleared.Test whether the existing code of the remote control has been successfully cleared: When you finish the clearing action, you can press any button of the copy remote control. If the LED does not flash immediately at this time, it will flash after 2 seconds, that means the original code of the copied remote control has been completely cleared. If the LED still flashes quickly and immediately, the code still exists and needs to be cleared again.3. Recovery the Cleared Code:If the useful codes are cleared by mistake, you can press the start and mute buttons (below two buttons) marked on the remote control at the same time. After about 3 seconds, the LED will flash 3 times and then It starts to flash quickly, which means that the recovery is successful.Warm Tip:1. Before using our copy remote control to copy, first clear the existing code of the self-copy remote control.2. The self-copy remote control cannot copy the rolling code, such as HCS301.Note:1. Due to the different monitor and light effect, the actual color of the item might be slightly different from the color showed on the pictures. Thank you!2. Please allow 1-3mm measuring deviation due to manual measurement.1 X Copy Remote Control
