30.5x30.5mm F405 F4 Flight Controller with 5V 10V BEC Output & 60A BLS 4in1 3~6S ESC Stack for FPV Racing Drones

Specifications Model F405 FC 60A ESCIterm Name 30 5x30 5mm StackF4 F405 Flight Controller Product Parameters MCU STM32F405RGT6 168MHzGyroscope Mpu6500Baro Bmp280OSD Betaflight SPI OSD DJI HD OSD UART5 Black box 16MB6x Uarts UART 1 2 3 4 5 64x PWM outputs1x I2C2x LEDs for FC STATUS Blue and 3 3V indicator Red and 5V indicator Red and 9V indicator Red USB Type C USB2 0 1x JST SH1 0 8pin connector Gnd Vbat S1 S2 S3 S4 Curr Rx3 1x JST SH1 0 6pin connector 9V GND T5 R5 GND R2 VTX 9V filtered powerDJI FPV OSD is supported by any spare UARTLED 4 LED independent pads support WS2812 programming lamp output Receiver Support Sbus crsf ibus SBUS XBUS receiver The default receiver input is UART2 You can solder ELRS RX on UART2 Power Input voltage 3 6SBEC 5V 10V 3A max dual channel BEC supports stable power supply on the sky side of DJILDO 3 3V Max 1AFC Firmware BetaFlight firmware DAKEFPVF405INAV firmware DAKEFPVF405Mounting Installation size 30 5mm 30 5mm The installation hole is M4 and supports shock column installationExternal size 36mm 36mmFlight controller weight 6 9gFlight controller onboard voltage sensor BLHeli S 60A 3 6S DShot600 4 in 1 ESC Support Dshot600 Dshot300 Dshot150 Oneshot125 Multishot PWM control signalPower supply voltage 3 6S 12 26V Continuous working current 45A 60ANo built in 5V BEC outputFirmware BLHeli SScrew hole spacing 30 5 30 5MMAperture 4MMWeight 14 6gFeature The ESC has an on board filter capacitor that suppresse
