3.5 Inch 320 X 480 TFT LCD Display Touch Board For Raspberry Pi 2/B+

This is the updated V2 version (Update in 2016-03-21, CN warehouse at present). EU & USA warehouse are still the old version.Parameter:LCD TypeTFTLCD InterfaceSPITouch Screen TypeResistiveTouch Screen ControllerXPT2046Colors65536BacklightLEDResolution320*480 (Pixel)Aspect Ratio8:5Power ConsumptionTBDBacklight CurrentTBDOperating Temp. (Centigrade)TBDInterface Definition:PIN NO.SYMBOLDESCRIPTION1, 173.3VPower positive (3.3V power input)2, 45VPower positive (5V power input)3, 5, 7, 8, 10, 12, 13, 15, 16NCNC6, 9, 14, 20, 25GNDGround11TP_IRQTouch Panel interrupt, low level while the Touch Panel detects touching18LCD_RSInstruction/Data Register selection19LCD_SI / TP_SISPI data input of LCD/Touch Panel21TP_SOSPI data output of Touch Panel22RSTReset23LCD_SCK / TP_SCKSPI clock of LCD/Touch Panel24LCD_CSLCD chip selection, low active26TP_CSTouch Panel chip selection, low active Package included:1 x 3.5 Inch 320 X 480 TFT LCD Display Touch Board
