3.3V ADS1115 ADC Module for Raspberry Pi 3/2 / B + / I2C RPI ADS1115 ADC Analog to Digital Converter

Description The RPI ADS1115 ADC module is a precision analog to digital converter AD C where the ADS1 11 5 is a chip capable of providing 1 6 bit sampling accuracy using an ultra smalI MSOP 1 0 package Data is transmitted through the I2C compatible serial interface with 4 channels of I2C addresses to choose from and th e working power supply only needs 3 3V Its main function is that it can be used to detect analog signals and convert t hem to digital signals You can connect the analog signal control stick or other analog sensors such as NTC temperature and dust sensors to RPi through this R PI ADS1115 ADC module and read the analog signals collected by the device Specification Size 65 0mm x 30 0mm x 18 0mmPower Supply 3 3VAnalog Input Voltage GND to VDDPROGRAMMABLE DATA RATE 8SPS to 860SPSINTERNAL LOW DRIFT VOLTAGE REFERENCEINTERNAL PGA AvailableResolution 16 bitI2C™ INTERFACE Pin Selectable AddressesChannels Number 4 SINGLE ENDED OR 2 DIFFERENTIAL INPUTSPROGRAMMABLE COMPARATOR 2 3 16INTERNAL NTC Support AvailablePackage included 1 x ADS1115 ADC Module
