3 in 1 6/8/10/15mm Woodworking Self Centering Dowelling Jig Drill Guide Locator Kit

Features: 1. Adjustable drill guide easy to meet your drill requirements. 2. Equpped with a dedicated clamp board you do not need to use an locking pliers to clamp the wood board when puching holes in the side. 3.Come with 6/8/10mm drill bushings and twist drill to accurately drill corresponding size of holes. 4.Forged by premium tool steel the drill bushings are of good strength and long durability. 5.Strict and fine workmanship ensures high precision and long service life. Specification: Drill Guide Material: 6061 Aluminum Alloy Drill Bushing Material: Nitride Tool Steel Drill Thickness: 10-180mm Side Hole Diameter: 15mm Direct Hole Diameter: 6/8/10mm Slide Stroke: 5-90mm Side Hole Stroke: 23-43mm Size: Shown as picture Weight: Approx. 1550g/54.7oz Package list: 1 * Extension Locator 9 * Drill Bushings (3pcs 6mm 3pcs 8mm 3pcs 10mm) 2 * Knurled Bolts 4 * Limit Ring (1pc 6mm 1pc 8mm 2pcs 10mm) 2 * Star Screws 1 * 15mm Tapper 3 * Drill Bits 6/8/10mm 1 * Hook Spanner 1 * Clamp Board 1 * Slider Set 1 * Main Board 2 * Washers 0.5/1mm 1 * Hex Wrench 1 * User Manual Note: Since the slider slides 2mm each time it can only be aligned with the center of the plate of 10 14 18 22mm etc. If the thickness of your plate is not these thicknesses it can t be aligned with the center to punch hole without adding washer.
