3 In 1 IV8S AHD TVI CVI CVBS 1080P CDD Camera Detector Tester Monitor Analog PTZ

Features : Video signal testing. Video monitor tester,high-resolution 5.0inches 800(RGB) x 480 wide viewing angle display. Support PAL/NTSC standard video signal. PTZ controller. Image generator. DC 12V 1A output power. Audio testing. Enhanced network cable testing. VGD/HDMI input. LED indicator. The battery graphic display. Specification : Display: 5 inch VGA TFT-LCD,800(RGB) x 480 resolution LCD adjustment:Brightness,Contrast,Saturation adjustable Video in/out: 1 channel BNC input & 1 channel BNC output VGA/HDMI input:support VGA/HDMI 1.0 video input.The maximum resolution is 1920*1080 PTZ controller:Communicaiton:support RS485 PTZ protocols:Compatible with protocols PELCO-D/P Baud rate:600,1200,2400,4800,9600,14400bps Power Adapter:DC5V(1.5A) Battery:built-in 18650 2600mA battery x 2 Rechargeable:after charging 3-4 hours,working time lasts 11 hours Operation setting: OSD menu,select language English,etc Working temperature:-10~+50 Size:170mm*110mm*48mm Power Adapter Plug: EU type,US type Package Includes : 1 x HD Coaxial Tester 1 x Adapter DC5V 1.5A (With USB Cable) 1 x BNC Cable 1 x RS485 Connector 1 x Multimeter Test Lead with Red and Black Clip 1 x Power Output Conversion Cable 1 x Audio Cable 1 x Lanyard 1 x Tool Bag 1 x User Manual Details Pictures :
