2D QR 1D Barcode Scan Engine EP3000 Scanner Module Support Format RS485/ USB/RS232

Feature: The EP3000 Fixed mount 2D Imager Module provides a self-contained 1D and 2D barcode scanning solution, whether decoding phone screens or paper. It offers many differentiating features that simplify installation (e.g. cable connector compatibility and more mounting options) and enhances performance (e.g. Wide Angle and Megapixel optics options, a wider choice of non-laser aimers and illumination, enhanced scan time and print contrast, and higher operating temperature range). Its unique design simplifies installation and deployment for a wide range of kiosk applications. Parameter: Performance parameter Image Sensor 960*640 CMOS Decodable system 1D EAN-8, EAN-13, EAN-13 2 add-on, EAN-13 5 add-on, ISSN, ISBN, UPC-A, UPC-E, Code 32, Code 39, Code 93, Code 128, Codabar, Industrial 2 of 5, Interleaved 2 of 5, Matrix 2 of 5, GS1 DataBar(RSS14) GS1 DataBar Limited, GS1 DataBar Expanded, ISBT-128, GS1-128, code39FULLASCII 2D PDF417, QRcode, MicroQR, Aztec, Datamatrix Scanning Range Test code Minimum range Maximum range 5mil code39 2cm 4cm UPC-13mil 1cm 11cm 20 mil code39 3cm 10cm 20 mil QR Code 1cm 9cm System compatibility Linux, Android, MAC OS, Windows XP, 7, 8, 10 Scan mode Auto-sensing scan Support keyboard English, French, Italian, German, Spanish, Finnish, Japanese, Russian, Arabic, Irish, Polish, Dutch, Czech, Portuguese (Portuguese, Brazilian) Swedish, Turkish F, Turkish Q, Greek, Belgian (French) Support for bar code language Simplified Chinese characters (win system) Invoice function Support (only for the Chinese market) (under the win system) Minimum recognition accuracy Code 39 code 5mil Scan barcode type One-dimensional two-dimensional bar code for paper and film; one-dimensional two-dimensional bar code for phones, tablets, etc. Motion tolerance 2.2 m / sec Printing contrast 35% Secondary development Support secondary development, through serial port instructions Barcode output editing Adding suffixes is not supported Recognition angle range Angle 360 elevation angle 60 declination 70 Environmental parameter Drop resistance Can withstand 2 meters of free fall and fall 5 times Waterproof and dustproof Meet the IP54 standard range of working temperature -20-55 C Storage temperature range -20-60 C Operating humidity range 5-95% non-condensing state Save humidity range 5-95% non-condensing state Human interaction Buzzer Start prompt, decoding success prompt Physical parameter Host net weight 158g With packaging and accessory weight 330g Host size (length * width * height mm) 76.72mm* 66.3mm*64.7mm Package size (length * width * height mm) 184mm*110mm*84mm Data line length 180CM (3CM) Communication Interface USB (drive-free) serial port (TTL, RS232, RS485) Wiegand Operating Voltage 5V-20V USB interface Automatic induction Standby power 118mA/0.59W Serial interface Automatic induction Standby power 118mA/0.59W Working power 149mA/0.745W Working power 149mA/0.745W Working maximum power 151mA/0.755W Working maximum power 151mA/0.755W Package includes: 1 x Scanner
