26.5*26.5mm NameLessRC AIO412T F411 Flight Controller MPU6000 2-4S HV 5V/2.5A BEC

Specification Brand name NameLessRCItem name NameLessRC AIO412T Flight ControllerProcessor STM32F411Sensor MPU 6000 connected by SPI Input Voltage 2 4S Lipo or 2 4S HV LipoSize 33 33mmWeight 4 6g W O battery wire Mounting Hole Distance 26 5 26 5mm FC SPECIFICATIONS CPU STM32F411CEU6 100MHZ Six Axis MPU6000 SPI connection Size 33 33mm board Built in 5V 2 5A BEC with LC filter OSD Built in BetaFlight OSD Receiver Support DSM2 X receiver Frsky XM XM Receiver Frsky R9M Futaba Receiver Flysky Receiver TBS Crossfire Receiver Support programmable LED Built in current sensor Weight 4 6g W O battery wire ESC SPECIFICATIONS Power supply 2 4S LiPo LiPo HV 7 4v 17 4v Continue current 12APeak current 15AFirmware BLHELI SMotor Connectors 1 25mm header pins connectorDefault protocol DSHOT600 Features The largest support 4S Lipo HV battery with Current meter F411 Flight Controller BEC 5V 2 5A MPU6000 Gyro Include Buzzer pad Invert and non invert SBUS port Light designPackage Included 1 X NameLessRC AIO412T Flight Controller
