24VDC 4N Nema34 Brake Stepper Motor Nema 34 98mm Body Length Nema34 Brake
Характеристики
| Ambient Temperature: | -20℃~+50℃ |
| Application: | Industrial Machinery |
| Brake: | 24V 4N brake |
| Brand Name: | sumtor |
| Certification: | ce,ISO,ROHS |
| Current / Phase: | 6A |
| Dielectric Strength: | 500VAC/1 minute |
| Frame size: | NEMA 34, 86mm |
| Holding Torque: | 6.5N.m (903oz-in) |
| Lead wire number: | 4 |
| Model Number: | Stepper Motor 86HS9860B4SC |
| Motor Length: | 98 mm |
| Phase: | 2 |
| Resistance Accuracy: | ±10% |
| Step Angle Accuracy: | ±5% |
| Step Angledegrees: | 1.8 |
| Structure: | stepper motor brake |
| Temperature Rise: | 80℃ Max |
| Type: | Hybrid |
