24V DC Blower 13Kpa High Pressure Small Brushless Blower DC Blower Pipe Fan Dust Sampling Collecting Instrument

Product advantages: High pressure (full pressure 13KPA) large air volume (680 liters / minute) low noise (distance from 1M far from 44dB to 1KPa) long life (4 hours of operation, 30 hours of life of up to 25,000 hours) high efficiency high speed, high stability and so on. This brushless fan has stable start, small size, low noise, low temperature rise, long service life, high efficiency, accurate accuracy, energy saving and environmentally friendly materials. Technical parameters: WM9290-24V Project Unit WM9290-24V Voltage V 24V Max Speed rpm 28000+/-5% Max Current A 8 Max airflow L/min 680 Max air pressure current A 3.2 Max air pressure KPa 13 Coil connection method "Y" Max Power W 190 Size mm D:92mm, H:101mm Weight g 380 Holzer angle degree 120 Bearing NSK double balls bearing Rotor magnet pole number 2 Noise db(A) 45(1M-1KPa) Speed adjustment 0-5V Or PWM WM9290-12V Project Unit WM9250-12V Voltage V 12V Max Speed rpm 22000+/-10% Max Current A 16 Max airflow L/min 650 Max air pressure KPa 12.5 Coil connection method "Y" Max Power W 240 Size mm D:92mm,H:100mm Weight g 550 Holzer angle degree 120 Bearing Japan NSK double balls bearing Rotor magnet pole number 2 Noise db(A) 42(1M-1KPa) Speed adjustment 0-5V Or PWM Controller Drive +5V Hall power supply 0-5V Input HU Hall U Input VSR Speed control signal HV Hall V Input GND Ground HW Hall W Input ENA enable input GND Hall negative electrode FR Positive reversal U Phase U FG Speed pulse output V Phase V GND Negative power supply W Phase W VCC Positive power supply Package Included: 1 x High Pressure Blower(without drive) Or 1XDrive
