24V/36V/48/60V 250W/350W Brushless Controller Battery Speed LCD Instrument For MTB E-Bike Scooter with Hall

Description: 1. Moto controller and LCD display adapts waterproof design you can use it Conveniently at your daily time . 2. LCD display can clearly show the state and data, backlight enables you to see screen clearly in dim environment, buttons for quick operation, easy to use. 3. Brushless type of controller, working silently and sensitive to the state of electric bike. 4.LCD display comes with mount ,suitable for 22mm handlebar. 5. Suitable for electric bicycles, cars, scooters. 6. Easy to install and use, comes with mount for LCD display and suitable for 22mm handlebar. 7.Fit for different battery: lead-acid, Li-Fe battery, LNCMO battery {Li(NiCoMn)O2} and so on. For different material there is different under voltage protecting point. 8. Fit for DC brushless gear motor lower than 350w, and gearless motor, and high speed motor and so on 9.Suitable for: 250W/350W brushless DC motor (include with hall sensor and without hall sensor) Specification: Brushless Motor Controller: Voltage:DC 24V/36V/48V/60V Power:250W/350W Low volts:DC 19V/30V/41V/52V Max current available: 10A-20A (default setting 13A) 60 / 120 (Automatically indentify ) Operating Conditions: -40 ~80 Material: Plastic + Metal Controller Function: 1. 1:1 pas power 2. Brake and cut off power 3. Connect with lcd display 4. Throttle 5. Horn/light power port 6. Self learning 7. Hall linear ebs brake 8. Cruise 9. 6km/h boosting Controller Feature: 1. Automatically indentify motor phase and angle 2. Dual mode (When motor hall work normally, controller work with hall mode. When motor hall damaged, controller can intelligently test it and change to no-hall mode and keep on work. (other controller if not double mode, cannot work if motor hall damaged) 3. Can control and match with other electric parts 4. When battery voltage is not enough the controller will automatically lower current, this will protect your battery for longer life. LCD Display: Brief introduction to 6 mosfet controller dual mode type for lithium battery Rated working voltage: 24V/36V/48V/60V Power available :250W/350W Max current available: 10A-20A (default setting 13A) Battery Voltage Undervoltage Protection Point: DC 19V/30V/41V/52V LCD Display Function: Battery indicator, Motor power indicator, speed stage, bike speed indicator, single trip distance, total trip distance, single trip time, battery detailed voltage, cruise control, assis control. 1. Adjust the brightness of backlight 2. Unit Changing, kilometer to mile, or mile to kilometer 3. Automatically indentify the voltage of battery 4. Sleep Time and Time Display Setting 5. Gear Setting 6. Accurate speed parameters 7. Limit the speed, speeding will brake 8. Start Mode Setting 9.Drive Mode Setting 10.Adjust the boost sensitivity 11. Change the strength and weakness of boost 12. Compatible magnetic points 13. Current and low voltage of controller setting 14. Total mileage accumulation and clearing 15. Cruise 16. Power-on password setting 17. 6km/h boosting and boosting at current speed LCD Display Error Code: 002 brake error 003 pas sensor error 004 boosting 6km/h cruise mode 005 timely cruise mode 006 battery level low 007 motor error(when the bike is without hall. ) 008 throttle error 009 controller error 010 communication receive error 011 communication sending error 012 DMS communication error Note: The diaplay is for MTB E-Bike Scooter with hall, otherwise is will display E007 error code. There are many kinds of brushless DC motor in the market, so for match with them, the controller has a "reset" function, after you connect all the wires necessary include "reset" wires, your motor will run automatically, and you can see if your motor run in right way, if yes, then disconnect the "reset" wires and forget them please, if your motor run in reverse direction, then disconnect the "reset" wires and connect them again quickly, now your motor will run in right direction, and after 2~3 seconds, disconnect the "reset" wires again, now the controller has match with your motor. And please note, keep the "reset" disconnect after this job, thanks a lot. Package Included: 1 X Motor Controller 1 X LCD Display Instrument with Switch
