24V 200W 2750 RPM Electric Brushed Bike Scooter Motor Clockwise 2 Wire ZY1016

Description: A multi purpose 24 volt 200 watt brushed electric motor rated at 2750 without load and a 10.9a rated current Features an 8mm 3/4 Moon drive shaft for an 11 tooth 6mm sprocket. The ZY and MY motor codes dictate small differences in some of the motors dimensions and specification Incorporates a welded mount bracket for easy fitment to multiple applications. The drive is clockwise. It can operate in forward or reverse. A welded mount bracket for easy fitment to multiple applications. Specification: Material: Copper wire, iron Color: Black Drive: Clockwise Voltage: 24 V Wattage: 200 W Model Number: ZY1016 Chain Size: 6mm (25H) Rated Current 10.9 A Rated Speed: 2750 RPM Outer Diameter: 101.37mm Wiring Length (approx.): 355mm Diameter of Fixing Hole(s): 5mm Shaft Diameter: 10mm Overall Height: 105mm Overall Width: 110mm Sprocket Thickness: 4mm Sprocket Diameter (Tip of Tooth to Tip of Tooth): 25mm Length of the Shaft on Which the Sprocket Sits: 24mm Smallest Distance Between Fixing Holes (Centre of Eye to Centre of Eye): 42.80mm Number of Teeth on Sprocket: 11mm Wiring: 2 (Nagative: Black ; Positive: Red) Greatest Distance Between Fixing Holes (Centre of Eye to Centre of Eye): 94.80mm Note: Please allow 1-3mm error due to manual measurement.Pls make sure you do not mind before you bid. The color may have different as the difference display,pls understand. Package Included: 1 X 24v 200w Brushed Bike Scooter Motor
