20x20mm Upgrade Betaflight F4 Noxe V1 Flight Controller AIO OSD 5V 8V BEC w/ Barometer and Blackbox for RC Drone FPV Rac

20x20mm Betaflight F4 Noxe V1 Flight Controller AIO OSD 5V 8V BEC for RC Drone Upgrade Firmware betaflight 4 1 0 FLYWOOF411 hex2 1 6mm Thickness PCB 3 Add 8V 3A dependent BEC4 The black box is upgraded to 16MB5 Add IIC SDA SCL Port6 Add CURT current signal input port7 Remove PPM Port 8 Support 2 6S Lipo inputSpecification Item Name Betaflight F4 Flight ControllerModel F4 Nox4 V1Version Standard Version Deluxe VersionStandard Version WithoutBarometer and BlackboxDeluxe Version With Barometer and BlackboxCPU STM32F411CMPU MPU6000Input Voltage Support 2 6S Lipo InputFirmware betaflight 4 1 0 FLYWOOF411 hexBuilt In Betaflight OSD Built in 5V 2 5A8V 3A BECSupport Spektrum 1024 2048 SBUS IBUS PPM and 3 3V Spektrum Satellite receiver Size 27x27mmMounting Hole 20x20mm M2 5Weight 4 3gApplication for less than 150mm frame kitDiagram Picture Instruction GND Ground4 5V Receiver power supply 5V BEC 5V 2 5A cont 8V BEC 8V 3A cont 3 3V LDO3 3V MAX 150MAVBAT share Lipo power 7 4V 26V 2 6S PWM1 PWM2 PWM3 PWM4 ESC SignalVOUT Video output for video TransmitterVIN Camera Video inputBUZ BUZ General active 5V buzzer for dbuz 5VLED LED Strip WS2812 LED signalRX1TX1 UART1RX2TX2 UART2RX2 DSM IBUS DSM2 DSMX IBUS RC Receive Software Settings RX2 SBUS SBUS RC Receive Software Settings RX2 RSSI Receiver signal strengthCAM C Camera controlCURT Current signal inputSDASCL IIC Package Included 1x F4 Noxe V1 Flight C
