20pcs DC 5-12V Adjustable Delay Timer Switch NE555 Relay Shield Module

Specification The power indicator LED and switch trigger timing indication LEDsTime delay can be adjusted 0 120 seconds For applications of Vehicle equipment delay to prevent car ignition prevention of high sudden current to burn components and devicesSize 40 x 20mmWorking voltage 5 12VFeature 1 After power on when there is an external trigger signal the module began to delay and output signal after the delay time reach the signal output finish 2 The delay time is adjustable the default delivery is 0 120 seconds 4 LED indicator light indicates the output level5 Can be connected to relay or other modules to achieve control of high current working condition6 with input power indicator7 Onboard test button can be used as a trigger button8 Input VCC 5 12VGND groundIN Trigger active high level trigger voltage 5 12V and power supply common ground 9 Output OUT 5 12V output signal The output voltage is related to the input voltage when not triggered the output is low when triggered into a high level after the end of the delay to a low level GND groundPackage included 20 x Adjustable NE555 module
