20mm DC 6V 22RPM Large Torque Gear Motor

Description: 20mm DC 6V 22RPM Large Torque Gear Motor Specification: Voltage: DC 6.0V No-load speed: 22rpm Locked rotor torque: 6kg.cm 1. Standard Operating Conditions Item Specification Rated Voltage DC 6.0V Gear Ratio 1/195 Rotation CCW/CW Motor Position All position in horizontal Temperature 0 - 30 Degree Celsius Humidity 30% - 95% 2. Performance of Motor Item Specification No-load Speed 4500 +/- 10%rpm No-load Current 35mA (Max) Stall Current 420mA (Max) Stall Torque 50g.cm 3. Performance of Gear Motor Item Specification Outer Speed 22 +/- 10%rpm No-load Current 60mA (Max) Stall Current 420mA (Max) Stall Torque 6.0kg.cm (Max) Rated Torque 3000g.cm Rated Current 180mA (Max) Rated Speed 15 +/- 10%rpm Noise 50dB 4. Dimension Item Specification The Outside Shafft Length 10.5mm Shaft End Play 0.05 - 0.50mm Screw Size M2.5 Diameter of Shaft 4 x D 3.5mm Outline Mounting Dimension Refer to the Outline Drawing 5. Product Drawings 6. Curve Drawings Package Included: 1 x Motor More Details:
