2.8 3.2 Inch TFT/SD Shield Expansion Board For DUE LCD Module SD Card Adapter Geekcreit for Arduino - products that work

Description 1 TFT LCD in a much faster speed using 84Mhz Ardiuno DUE2 The shield route all the LCD data pins to port PC1 PC8 and PC12 19 control pins to PD0 PD3 this design can acheive high speed data transfer three cycles per write strobe to the LCD to maximize LCD display speed3 The SPI interface for SD or flash control is route to the ISP header of forDUE so that high speed SPI transfer with DMA can be achieved The shield is compatible with forDUE and the following LCD 2 2 TFT LCD module 220x176 2 8 TFT LCD module 320x240 3 2 TFT LCD module with font IC 320x240 3 2 High resolution TFT LCD module with font IC 480x320 3 5 TFT LCD module with Font IC 480x320 Full viewing angle IPS panel 4 0 TFT LCD module with Font IC 480x320 4 3 TFT LCD module with Font IC 480x272 5 0 TFT LCD module with Font IC 800x480 7 0 TFT LCD module with Font IC 800x480 Features 1 Drive TFT LCD on forDUE by just plugging into forDUE main board no flying wires2 Compatible with 40 pin version LCD which is commonly used in TFT DUE shield3 Also comptabile with 32 pin version LCD which is commonly used in STM32 development board4 On board SD card slot with adjustable CS selection5 On board SPI flash footprint with adjustable CS selection for upgrade include font IC to draw text to the LCD and also support SPI Flash library6 LCD power 3 3V and 5V selectable through solder jumpers7 LCD backlight LEDA 3 3V 5V or PWM selectable through solder jumpers8 Pins are routed to r
