2.4ghz Wifi Signal Repeater Booster

One 5w booster + one 6dBi antenna change your poor wifi signal problem easily, and extend the signal range significantly by only connecting it to your router, without any installment. Easy to use and helpful.
How to use？
Step 1: Remove the antenna from the wireless router (Access point).
Step 2: Use RG316 cable to connect the booster and AP.
Step 3: Connect the antenna to the other end of booster.
Step 4: Plug in the power adapter.
Specifications
Support Standards IEEE 802.11b/g/n
Frequency 2400-2500MHz
Working Pattern TDD
RF Output Power 37dBm
Input Trigger Power Min 3dBm Max 20dBm
Transmit Gain 17dB typical
Receiver Gain 11dB typical
Switch Time Delay ＜1us
Noise Figure 3.0dB typical
Operating Humidity up to 95°rel. humidity
Working Voltage 6-18V DC
Operating Temp. -40℃ ~ +70℃
Indicating Lamp Transmitter: Green; receiver: Red
Weight 410g
Product Size 8.5cm x 5cm x 2cm
Package Size 20cm x 16cm x 6.5cm
What's in the box?
1 x Wifi Signal Repeater Booster
1 x 6dBi antenna
1 x Charger
