2.2KW 3HP 380V 5A 3 To 3 Phase Variable Frequency Inverter Motor Drive VSD VFD

Features Frequency setting mode digital setting analog setting serial communication setting PID setting and so on Built in PID control function can easily constitute a simple automated control system Other functions deceleration stop or freewheel stop DC brake automatic reset restart PLC program control and so on Provide a variety of fault protection over current overvoltage undervoltage over temperature phase loss overload and other protection Specifications Color BlackInput 3PH AC 380 440V10 50 60HzOutput 3PH 0 500HzPower 2 2KWCurrent 5AControl Method Voltage vectorBraking Resistor 250 Safety Precaution 1 Before wring please make sure that the input power is off 2 The wring work should be operated by the professional electrical engineer 3 The grounding terminals must be connected with the ground 4 Having paused circuit wiring emergently please make sure that the check is effective 5 Do not connect the output wire of the inverter with the shell and pay attention that the output wire should not be short circuited 6 Please check whether the voltage of the AC main circuit power is consistent with the rated voltage of the inverter 7 Do not do the voltage withstand test on the inverter 8 Please connect the brake resistor according to the wiring diagram 9 Do not connect the power to the U V W output terminals 10 Do not connect the contactor with the output circuit 11 Mare sure to install a protection cover before power on When removi
