2-Wires 15A Electrical Slip Ring Collector Ring Wind Turbine Generator Slip Ring

Feature: *The rotating contact surface is gold-gold and the precious metal contact ensures an extremely long working life; *360° smooth and unlimited rotation fully meets image and data transmission; *Complete product range customized products according to customer needs; *Suitable for PTZ electrical test equipment rotary table medical equipment CCTV security monitoring equipment robot exhibition / display equipment manufacturing and processing control equipment small wind turbines antennas and so on; *Low torque low noise wide range of applications can meet the requirements of various industries and can be customized according to customer needsCompact structure and smooth operation; Specification: Product name: Conductive slip ring Item model number: MW1215 Number of rings: 2 Rated current per ring (A): 15 Outer diameter (mm): 22 Length (mm): 45 Working life: 10 million revolutions Rated speed: 150RPM Working temperature: -30℃~80℃ Working humidity: 0~85% RH Contact material: precious metal Shell material: engineering plastic Rotating torque: 0.1N m; +0.03N m/6 circuits Protection class: IP51 Rated voltage: 0~380VAC/VDC Insulation resistance: ≥1000MΩ/500VDC Wire size: 10A=AWG#17; 20A=AWG#14; 30A=AWG#12; Wire length: standard length 300mm Dielectric strength: 500VAC@50Hz 60s Dynamic resistance change value:
